Low heat, near-silent, fanless method implemented!
The world's first left and right I / O placement for efficient management!
Slim & Sleek Style Design.
Specifications:
|
System |
|
| CPU Support | Intel® Celeron J1900 (up to 2.42GHz) |
| Memory | Support up to 8GB DDR3L |
| Core Logic | Intel® Bay Trail / Haswell |
| Net Work | 10/100/1000 Base-T Gigabit Ethernet |
| Power Supply | 12V Power Adaptor |
| Color | Black |
| System weight | 5.8 kgs |
| Dimension (WxHxD) mm | 384 x 324 x 194 mm |
| O/S | POSReady 7, Windows 7, Windows 8, Windows 10 |
| Storage | |
| HDD | 1 x 2.5″ SATA HDD |
| SSD | 1 x 2.5″ SSD SATA |
| I/O Ports | |
| Ports | 3 x External COM ( RJ Type, w/+5V/12V Power Selectable ) |
| USB Ports | 3 x External USB 2.0 Ports / 1 x External USB 3.0 Ports |
| Ethernet | 1 x 10/100/1000 Mbps (RJ45) |
| VGA | 1 x DB-15 VGA Interface |
| Cash Drawer | 1 x RJ11 (12V) |
| DC-IN | 12V DC-IN |
| Power Switch | 1 x Power Switch |
| Display | |
| LCD | 15″ TFT LCD Panel |
| Max. Resolutiion | 1024 x 768 |
| Brightness | 300 nits |
| Touch Screen | PCAP Multitouch Screen |
| Environmental | |
| Operating Condition | 0°C ~ 40°C, 20%RH ~ 80%RH |
| Storage Condition | -20°C ~ 60°C, 10%RH ~ 90%RH |
| Safety | |
| Safety standards | CCC / CE / FCC |
| Виробник | Poslab |
|---|---|
| Об'єм диска | - |
